Ledvance
4099854230172
Electrical unit for light-line system
Manufacturer part number: 4099854230172
Serie:
Type: TRUSYS FLEX T5 TRACK DT WT
EAN-code: 4099854230172
SKU Omnical: 4299487
Stock: 0.
Estimated lead time: 11 days *
PreOrder
YYD
$
106.49
per item
$
81.36
per item
CAD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
4099854230172 Ledvance Electrical unit for light-line system
Ledvance Electrical unit for light-line system TruSys® FLEX T5 TRACK T5 TRACK DT WT
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
Other
Lamp holder
G5
Width
(mm)
91.3
With control gear
No
Suitable for emergency lighting
No
Nominal voltage
(V)
220 - 240
Colour housing
White
Reflector
Other
Light sharing
Symmetric
Light outlet
Direct
Length
(mm)
1498.5
Protection class
I
Degree of protection (IP)
IP20
With light source
No
Voltage type
AC
Height/depth
(mm)
97
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming manufacturer's proprietary system
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Reflector
Rated life time L70/B50 at 25 °C
(h)
100000
Emergency power supply integrated
No
Type of wiring
Suitable for through wiring
Number of poles
5
Exchangeable control gear
No
Constant light output (CLO)
No
Beam angle adjustable
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Operation by Bluetooth
No
Compatible with Casambi
No
Rated ambient temperature according to IEC62722-2-1
(°C)
-25 - 40
Stock and logistics
Height
0.14 m
Width
1.54 m
Depth
0.13 m
Packaging
item
Weight
1.588 kg
HS code
94051190
