2CDS273103R0165
Miniature circuit breaker (MCB)
Manufacturer part number: 2CDS273103R0165
Serie: System pro M compact
Type: S 203M B16 NA
EAN-code: 4016779549776
SKU Omnical: 2029009
Stock:
4 items.
Delivery time: 1-2 business days.
InStock
UVK
$
270.51
per item
USD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
2CDS273103R0165 ABB Components Miniature circuit breaker (MCB)
ABB Components Miniature circuit breaker (MCB) 10 kA Automaat 3p+N B kar 16 A
Datasheet
Rated current
(A)
16
Number of poles (total)
4
Concurrently switching neutral conductor
Yes
Release characteristic
B
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
(kA)
10
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
(kA)
10
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
(kA)
25
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
(kA)
15
Rated voltage
(V)
400
Additional equipment possible
Yes
Voltage type
AC
Current limiting class
3
Over voltage category
3
Pollution degree
3
Width in number of modular spacings
4
Built-in depth
(mm)
69
Degree of protection (IP)
IP20
Number of protected poles
3
Frequency
(Hz)
50 - 60
Suitable for flush-mounted installation
No
Rated insulation voltage Ui
(V)
440
Rated impulse withstand voltage Uimp
(kV)
4
Ambient temperature during operating
(°C)
-25 - 55
Connectable conductor cross section multi-wired
(mm²)
0.75 - 25
Connectable conductor cross section solid-core
(mm²)
0.75 - 35
Explosion-proof
No
Flush-mounted installation
No
Power loss
(W)
10
Stock and logistics
Height
0.08 m
Width
0.08 m
Depth
0.093 m
Packaging
Package
Weight
0.5 kg
HS code
85362010
