3010658
Light scanner with background masking
Manufacturer part number: 3010658
Serie:
Type: QS18VN6AF300Q5
EAN-code: 662488106584
SKU Omnical: 4195146
Stock: 0.
Estimated lead time: 63 days *
PreOrder
T05
€
174,83
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
3010658 Banner Light scanner with background masking
Banner Light scanner with background masking Foto-elektrische sensor, diffuse sensor met instelbare achtergrondonde
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Adjustment range
(mm)
1 - 300
Rated switching distance
(mm)
300
Max. switching distance
(mm)
300
Type of electric connection
Connector M12
Type of switching output
NPN
Type of switch function
Change-over contact (NO/NC)
Construction type housing
Cuboid
Width sensor
(mm)
15
Height of sensor
(mm)
34.5
Length of sensor
(mm)
21.1
Material of optical surface
Plastic
Material housing
Plastic
Min. reflector distance
(mm)
1
Ambient temperature
(°C)
-20 - 55
Response time
(ms)
2.5
Switching frequency
(Hz)
700
Wavelength of the sensor
(nm)
640
Type of light
Polarity free red light
Material of cable sheath
Polyvinyl chloride (PVC)
Suitable for safety functions
No
Degree of protection (IP)
IP67
Stock and logistics
Height
0.14 m
Width
0.09 m
Depth
0.03 m
Packaging
Package
Weight
0.066 kg
HS code
85365019
