3049238
Light scanner with background masking
Manufacturer part number: 3049238
Serie:
Type:
EAN-code: 662488492380
SKU Omnical: 3375708
Stock: 0.
Estimated lead time: 34 days *
PreOrder
T05
€
405,32
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
3049238 Banner Light scanner with background masking
Banner Light scanner with background masking Foto-elektrische sensor, diffuse sensor met vaste achtergrondonderdruk
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Adjustment range
(mm)
50 - 2000
Rated switching distance
(mm)
2000
Max. switching distance
(mm)
2000
Type of electric connection
Connector M12
Type of switching output
PNP
Type of switch function
Change-over contact (NO/NC)
Construction type housing
Cuboid
Width sensor
(mm)
18
Height of sensor
(mm)
76.2
Length of sensor
(mm)
42
Material of optical surface
Plastic
Material housing
Metal
Min. reflector distance
(mm)
50
Ambient temperature
(°C)
-20 - 55
Response time
(ms)
1
Switching frequency
(Hz)
500
Wavelength of the sensor
(nm)
880
Type of light
Infrared light
Material of cable sheath
Polyvinyl chloride (PVC)
Suitable for safety functions
No
Degree of protection (IP)
IP67
Stock and logistics
Height
0.09 m
Width
0.05 m
Depth
0.05 m
Packaging
Package
Weight
0.146 kg
HS code
85365019
Country of Origin
US
