Carlo Gavazzi
SPD241201N
DC-power supply
Manufacturer part number: SPD241201N
Serie: SPD
Type: CG SCHAKELENDE VOEDING DIN-RAIL
EAN-code: 8032973924658
SKU Omnical: 1290738
Stock: 0.
Estimated lead time: 8 days *
PreOrder
YPW
€
122,96
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
SPD241201N Carlo Gavazzi DC-power supply
Carlo Gavazzi DC-power supply CG SCHAKELENDE VOEDING DIN-RAIL 120W, 24V SCHROEF AUTOM.115/230VAC
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Voltage type of supply voltage
AC/DC
1st secondary output voltage
(V)
24 - 24
Nominal value output current 1
(A)
5
Max. output current 1
(A)
5
Width
(mm)
64
Secondary voltage adjustable
Yes
Short-circuit-proof
Yes
Rated supply voltage at AC 50 Hz
(V)
90 - 264
Rated supply voltage at AC 60 Hz
(V)
90 - 264
Rated supply voltage at DC
(V)
210 - 370
Output voltage stabilized
Yes
Power output
(W)
120
Stabilized
Yes
Type of electric connection
Screw connection
Rail mounting possible
Yes
Wall mounting possible
No
Modular version
No
Built-in height
(mm)
119
Direct mounting possible
No
Height
(mm)
124.5
Depth
(mm)
119
Performance level according to EN ISO 13849-1
Level a
Degree of protection (IP)
IP20
Nominal value output voltage 1
(V)
24
Built-in width
(mm)
64
SIL according to IEC 61508
1
Degree of protection (NEMA)
1
Stock and logistics
Height
160 mm
Width
160 mm
Depth
88 mm
Packaging
item
Weight
800 g
HS code
85044090
