Eaton
102268
Miniature circuit breaker (MCB)
Manufacturer part number: 102268
Serie: xEffect
Type: FAZ-D13/3-NA
EAN-code: 4015081021444
SKU Omnical: 2069650
Stock: 0.
Estimated lead time: 28 days *
PreOrder
M88
$
250.79
per item
$
163.01
per item
USD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
102268 Eaton Miniature circuit breaker (MCB)
Eaton Miniature circuit breaker (MCB) Installatie-automaat (MCB) FAZ-NA, 3P, 13A, D-curve, 15kA, UL-cert.
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Rated current
(A)
13
Number of poles (total)
3
Concurrently switching neutral conductor
No
Release characteristic
D
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
(kA)
0
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
(kA)
0
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
(kA)
15
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
(kA)
15
Rated voltage
(V)
415
Additional equipment possible
Yes
Voltage type
AC
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
3
Built-in depth
(mm)
70.5
Degree of protection (IP)
IP20
Number of protected poles
3
Frequency
(Hz)
50 - 60
Suitable for flush-mounted installation
No
Rated insulation voltage Ui
(V)
440
Rated impulse withstand voltage Uimp
(kV)
4
Ambient temperature during operating
(°C)
-25 - 75
Connectable conductor cross section multi-wired
(mm²)
1 - 25
Connectable conductor cross section solid-core
(mm²)
1 - 25
Explosion-proof
No
Flush-mounted installation
No
Power loss
(W)
6
Stock and logistics
Height
0.076 m
Width
0.055 m
Depth
0.107 m
Packaging
box
Weight
0.384 kg
HS code
85362010
Country of Origin
ES
