Eaton 120656
Eaton

120656

Earth leakage circuit breaker
Manufacturer part number: 120656
Serie: xPole
Type: mRB6-16/3N/B/03-A

EAN-code: 4015081184866
SKU Omnical: 2069030

Stock: 140 items.

Delivery time: 1-2 business days.
InStock

M76
252,58 per item
149,78 per item
EUR | Excluding VAT

Quantity
items
Add to cart
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
paypal
visa
mastercard
wire-transfer
120656 Eaton Earth leakage circuit breaker
Eaton Earth leakage circuit breaker Aardlekautomaat (RCBO) mRB6, B-kar., 16A, 300mA, 4P incl. N, 6 kA

Datasheet

Number of poles (total)
4
Number of protected poles
4
Rated voltage (V)
400
Rated current (A)
16
Rated fault current (A)
0.3
Leakage current type
A
Current limiting class
3
Rated short-circuit breaking capacity according to EN 60898 (kA)
6
Rated short-circuit breaking capacity according to IEC 60947-2 (kA)
0
Frequency
50 Hz
Release characteristic
B
Concurrently switching neutral conductor
Yes
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
4
Built-in depth (mm)
70
Degree of protection (IP)
IP20
Suitable for flush-mounted installation
No
Surge current capacity (kA)
0.25
Voltage type
AC
Anti-nuisance tripping version
No
Rated insulation voltage Ui (V)
500
Rated impulse withstand voltage Uimp (kV)
4
Rated short-circuit breaking capacity according to EN 61009 (kA)
6
Rated short-circuit breaking capacity Icn according to EN 61009-1 (kA)
6
Disconnection characteristic
Undelayed
With interlocking device
No
Ambient temperature during operating (°C)
-25 - 40
Connectable conductor cross section solid-core (mm²)
1 - 25
Connectable conductor cross section multi-wired (mm²)
1 - 25
Flush-mounted installation
No

Stock and logistics

Height
0.075 m
Width
0.073 m
Depth
0.086 m

Packaging
item
Weight
0.485 kg
HS code
85362010
Country of Origin
RO
