Eaton
187804
Residual current circuit breaker (RCCB)
Manufacturer part number: 187804
Serie: xEffect
Type: FRCMM-40/4/01-B
EAN-code: 4015081854882
SKU Omnical: 3222071
Stock: 0.
Estimated lead time: 36 days *
PreOrder
M88
€
1.476,49
per item
€
959,72
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
187804 Eaton Residual current circuit breaker (RCCB)
Eaton Residual current circuit breaker (RCCB) Aardlekschakelaar digitaal (RCCB) FRCMM, 40A, 4P, 100mA, 10kA, B-type
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Number of poles
4
Rated fault current
(A)
0.1
Rated current
(A)
40
Leakage current type
B
Selective protection
No
Rated voltage
(V)
240
Mounting method
DIN rail
Short-circuit breaking capacity (Icw)
(kA)
10
Surge current capacity
(kA)
3
Frequency
50 Hz
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Width in number of modular spacings
4
Built-in depth
(mm)
77.5
Short-time delayed tripping
No
Rated insulation voltage Ui
(V)
440
Rated impulse withstand voltage Uimp
(kV)
4
With interlocking device
Yes
Ambient temperature during operating
(°C)
-25 - 75
Pollution degree
2
Connectable conductor cross section multi-wired
(mm²)
1.5 - 16
Connectable conductor cross section solid-core
(mm²)
1.5 - 50
Voltage type
AC
Explosion-proof
No
RAL-number (similar)
7035
Stock and logistics
Height
0.08 m
Width
0.075 m
Depth
0.09 m
Packaging
item
Weight
0.48 kg
HS code
85362010
Country of Origin
DE
