Eaton
211780
Miniature circuit breaker (MCB)
Manufacturer part number: 211780
Serie: xEffect
Type: AZ-2-C32
EAN-code: 4015082117801
SKU Omnical: 2069674
Stock: 0.
Estimated lead time: 35 days *
PreOrder
M88
$
176.81
per item
$
114.93
per item
USD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
211780 Eaton Miniature circuit breaker (MCB)
Eaton Miniature circuit breaker (MCB) Installatie-automaat (MCB) AZ, C-kar., 32A , 2P, 25 kA
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Rated current
(A)
32
Number of poles (total)
2
Concurrently switching neutral conductor
No
Release characteristic
C
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
(kA)
0
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
(kA)
0
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
(kA)
25
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
(kA)
25
Rated voltage
(V)
400
Additional equipment possible
Yes
Voltage type
AC
Current limiting class
3
Over voltage category
3
Pollution degree
2
Width in number of modular spacings
3
Built-in depth
(mm)
75
Degree of protection (IP)
IP20
Number of protected poles
2
Frequency
(Hz)
50 - 60
Suitable for flush-mounted installation
No
Rated insulation voltage Ui
(V)
440
Rated impulse withstand voltage Uimp
(kV)
4
Ambient temperature during operating
(°C)
-25 - 55
Connectable conductor cross section multi-wired
(mm²)
2.5 - 50
Connectable conductor cross section solid-core
(mm²)
2.5 - 50
Explosion-proof
No
Flush-mounted installation
No
Stock and logistics
Height
0.077 m
Width
0.056 m
Depth
0.092 m
Packaging
box
Weight
0.466 kg
HS code
85362010
Country of Origin
CZ
