Eaton 274043
Eaton

274043

Residual current circuit breaker (RCCB)
Manufacturer part number: 274043
Serie: xPole
Type: PFIM-63/2/003-A-MB

EAN-code: 4015082740436
SKU Omnical: 1046693

Stock: 88 items.

Delivery time: 1-2 business days.
InStock

M76
287,65 per item
170,58 per item
EUR | Excluding VAT

Quantity
items
Add to cart
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
paypal
visa
mastercard
wire-transfer
274043 Eaton Residual current circuit breaker (RCCB)
Eaton Residual current circuit breaker (RCCB) Aardlekschakelaar (RCCB) PFIM 63A, 2P, 30mA, type A

Datasheet

Number of poles
2
Rated voltage (V)
0
Rated current (A)
63
Rated fault current (A)
0.03
Mounting method
DIN rail
Leakage current type
A
Selective protection
No
Short-circuit breaking capacity (Icw) (kA)
10
Surge current capacity (kA)
0.25
Frequency
50 Hz
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Construction size (according to DIN 43880)
1
Width in number of modular spacings
2
Built-in depth (mm)
60
Short-time delayed tripping
No
Rated insulation voltage Ui (V)
440
Rated impulse withstand voltage Uimp (kV)
4
With interlocking device
Yes
Ambient temperature during operating (°C)
-25 - 60
Pollution degree
2
Connectable conductor cross section multi-wired (mm²)
1.5 - 16
Connectable conductor cross section solid-core (mm²)
1.5 - 35
Voltage type
AC
Explosion-proof
No
Power loss (W)
9.7
RAL-number (similar)
7035

Stock and logistics

Height
0.075 m
Width
0.037 m
Depth
0.086 m

Packaging
item
Weight
0.244 kg
HS code
85362010
Country of Origin
RS
