Eaton
276306
Main switch for distribution board
Manufacturer part number: 276306
Serie: xPole
Type: Z-SWL230/SS
EAN-code: 4015082763060
SKU Omnical: 2069487
Stock:
26 items.
Delivery time: 1-2 business days.
InStock
M78
$
71.16
per item
$
51.88
per item
CAD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
276306 Eaton Main switch for distribution board
Eaton Main switch for distribution board Schakelaar Z, 250VAC, 16 A, Contacten 2M, signaallamp, Breedte 1TE
Datasheet
Switching function
Control switch
Number of normally open contacts
2
Number of normally closed contacts
0
Number of change-over contacts
0
Number of poles
2
Rated current
(A)
16
Rated voltage
(V)
250
Min. rated voltage
(V)
230
Rated switching capacity
(kA)
0.016
Short-circuit breaking capacity (Icw)
(kA)
0.02
Voltage type
AC
Forced segregation (according to DIN VDE 0113)
No
With signal lamp
Yes
Colour calotte
Other
Lamp type
LED
Lamp socket
Other
Max. lamp power
(W)
2
Width in number of modular spacings
1
Built-in depth
(mm)
80
Degree of protection (IP)
IP40
Number of contacts as normally open contact
2
Number of contacts as normally closed contact
0
Number of contacts as change-over contact
0
Imprint/indication
Other
Stock and logistics
Height
0.072 m
Width
0.02 m
Depth
0.082 m
Packaging
box
Weight
0.072 kg
HS code
85364900
Country of Origin
ES
