ETI
432000016
Residual current circuit breaker (RCCB)
Manufacturer part number: 432000016
Serie: Aardlekschakelaar EFI
Type: 2p
EAN-code: 3838895521433
SKU Omnical: 3334387
Stock: 0.
Estimated lead time: 64 days *
PreOrder
HD6
€
296,61
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
432000016 ETI Residual current circuit breaker (RCCB)
ETI Residual current circuit breaker (RCCB) Aardlekschakelaar EFI-2 100A 30mA 2p
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Number of poles
2
Rated fault current
(A)
0.03
Rated current
(A)
100
Leakage current type
A
Selective protection
No
Rated voltage
(V)
230
Mounting method
DIN rail
Short-circuit breaking capacity (Icw)
(kA)
10
Surge current capacity
(kA)
4
Frequency
50/60 Hz
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Construction size (according to DIN 43880)
87.5
Width in number of modular spacings
2
Built-in depth
(mm)
68
Short-time delayed tripping
No
With interlocking device
No
Ambient temperature during operating
(°C)
-25 - 55
Pollution degree
2
Connectable conductor cross section multi-wired
(mm²)
1 - 25
Connectable conductor cross section solid-core
(mm²)
1 - 35
Voltage type
AC
Explosion-proof
No
Stock and logistics
Height
6.8 cm
Width
3.6 cm
Depth
8.8 cm
Packaging
box
Weight
0.244 kg
HS code
85362090
