Lapp
2170886
Data and communication cable
Manufacturer part number: 2170886
Serie: ETHERLINE
Type: Profin.2p cab.Cat.5/
EAN-code: 4044773473186
SKU Omnical: 1125085
Stock:
965 x 1 meter.
Delivery time: 1-2 business days.
InStock
YLV
€
328,85
per 100 meter
€
223,29
per 100 meter
EUR | Excluding VAT
Quantity
x 1 meter
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
2170886 Lapp Data and communication cable
Lapp Data and communication cable ETHERLINE PN Cat.5 Y FLEX FC - 1 MTR
Datasheet
Nominal cross section conductor
(mm²)
2
AWG size
Other
Conductor category
Class 2 = stranded
Number of cores
2
Stranding element
Quad
Material core insulation
Polyolefin
Specification core insulation
Other
Core identification
Colour
Screen over stranding element
None
Screen over stranding
Foil + braiding
Material outer sheath
Polyvinyl chloride (PVC)
Specification material outer sheath
Other
Colour outer sheath
Green
Cable geometry
Round
Halogen free according to IEC 60754-2
No
Flame retardant
According to IEC/EN 60332-3-24
Low smoke (according to EN 61034-2)
No
Low smoke according to IEC 61034-2
No
Outer diameter approx.
(mm)
6.5
Min. permitted bending radius, moving application/free movement
(mm)
54.4
Min. permitted bending radius, stationary application/permanent installation
(mm)
54.4
Permitted cable outer temperature during assembling/handling
(°C)
-20 - 60
Permitted cable outer temperature after assembling without vibration
(°C)
-40 - 80
Category
5
NVP value
(%)
63
UV resistant
Yes
Yes
No
No
No
No
No
No
No
Stock and logistics
Weight
0.067 kg
HS code
85444995
Country of Origin
QU
