Ledvance
4058075708204
High bay luminaire
Manufacturer part number: 4058075708204
Serie:
Type: HB COMP V 225W 840 110DEG IP65
EAN-code: 4058075708204
SKU Omnical: 4223820
Stock: 0.
Estimated lead time: 11 days *
PreOrder
YYD
€
290,00
per item
€
221,56
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
4058075708204 Ledvance High bay luminaire
Ledvance High bay luminaire HIGH BAY COMPACT 225W 840 110DEG IP65
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Lamp holder
None
Suitable for number of lamps
0
With control gear
Yes
Suitable for emergency lighting
No
Nominal voltage
(V)
220 - 240
Material housing
Aluminium
Colour housing
Black
With protective cover
Yes
Material reflector
Other
Light sharing
Symmetric
Length
(mm)
300
Height/depth
(mm)
50
Protection class
I
Degree of protection (IP)
IP65
Impact strength
IK06
Ball-proof
No
Luminaire with limited surface temperature, sign "D“
Yes
With light source
Yes
Voltage type
AC
Nominal current
(mA)
980 - 980
Reflector
None
Rated luminous flux according to IEC 62722-2-1
(lm)
27000
Colour of light
White
Colour temperature
(K)
4000 - 4000
Colour rendering index CRI
80-89
Suitable for auxiliary lamp
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Diffuser lens/optic/panel
Beam angle
Extreme wide beam >80°
Colour consistency (McAdam ellipse)
SDCM5
Rated life time L70/B50 at 25 °C
(h)
50000
Rated ambient temperature according to IEC62722-2-1
(°C)
-20 - 45
Emergency power supply integrated
No
Filament test according to IEC 60695-2-11
850 °C - 30 s
Max. system power
(W)
225
Luminaire efficacy
(lm/W)
120
Power factor
0.9
Outer diameter
(mm)
300
Type of wiring
Ending
Number of poles
3
Conductor cross section
(mm²)
1
Connection type
Other
Total harmonic distortion
20
Exchangeable control gear
No
Constant light output (CLO)
No
Colour temperature adjustable
No
Beam angle adjustable
No
Luminous flux adjustable
No
Max. number of luminaires per miniature circuit breaker B16
13
Max. number of luminaires per miniature circuit breaker C16
13
Operation by Bluetooth
No
Photobiological safety according to EN 62471
RG1
Stock and logistics
Height
0.35 m
Width
0.34 m
Depth
0.08 m
Packaging
box
Weight
2.438 kg
HS code
94051190
