Ledvance
4058075842823
Batten luminaire
Manufacturer part number: 4058075842823
Serie:
Type:
EAN-code: 4058075842823
SKU Omnical: 4347715
Stock: 0.
Estimated lead time: 11 days *
PreOrder
YYC
€
15,00
per item
€
11,68
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
4058075842823 Ledvance Batten luminaire
Ledvance Batten luminaire UNDERCABINET SOCKET FRAMELESS 830 DIM White Extension
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Suitable for number of lamps
0
Lamp holder
None
Width
(mm)
81
Type of control gear
Electronic ballast
With control gear
Yes
Suitable for emergency lighting
No
Electrical connection with connector system
Yes
Material
Plastic
Colour housing
White
With switch
No
Length
(mm)
179
Protection class
III
Degree of protection (IP)
IP20
Luminaire with limited surface temperature, sign "D“
No
Covering of the luminaire with thermally insulating material possible
No
With light source
Yes
Voltage type
DC
Nominal current
(mA)
110 - 110
Rated luminous flux according to IEC 62722-2-1
(lm)
250
Colour temperature
(K)
3000 - 3000
Colour rendering index CRI
80-89
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
Yes
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Rated life time L70/B50 at 25 °C
(h)
30000
Emergency power supply integrated
No
With movement sensor
No
Max. system power
(W)
3.85
Height/depth
(mm)
21
Type of wiring
Ending
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
Yes
Exchangeable control gear
No
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
G
Operation by Bluetooth
No
Compatible with Casambi
No
No
Luminaire efficacy
(lm/W)
50
Stock and logistics
Height
0.24 m
Width
0.09 m
Depth
0.03 m
Packaging
item
Weight
0.245 kg
HS code
94054231
