Ledvance
4058075843400
High bay luminaire
Manufacturer part number: 4058075843400
Serie:
Type:
EAN-code: 4058075843400
SKU Omnical: 4347724
Stock: 0.
Estimated lead time: 11 days *
PreOrder
YYC
€
43,00
per item
€
33,50
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
4058075843400 Ledvance High bay luminaire
Ledvance High bay luminaire Highbay Ufo 80W 865 IP65 Black
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Lamp holder
None
Suitable for number of lamps
0
Width
(mm)
230.4
With control gear
No
Suitable for emergency lighting
No
Nominal voltage
(V)
220 - 240
Material housing
Aluminium
Colour housing
Black
With protective cover
No
Light sharing
Symmetric
Length
(mm)
230.4
Height/depth
(mm)
80
Protection class
I
Degree of protection (IP)
IP65
Impact strength
IK05
Ball-proof
No
Luminaire with limited surface temperature, sign "D“
No
With light source
Yes
Voltage type
AC
Nominal current
(mA)
366 - 366
Reflector
None
Rated luminous flux according to IEC 62722-2-1
(lm)
9300
Colour temperature
(K)
6500 - 6500
Colour rendering index CRI
70-79
Suitable for auxiliary lamp
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Colour consistency (McAdam ellipse)
SDCM6
Rated life time L70/B50 at 25 °C
(h)
20000
Rated ambient temperature according to IEC62722-2-1
(°C)
-20 - 40
Emergency power supply integrated
No
Max. system power
(W)
80
Luminaire efficacy
(lm/W)
116
Power factor
0.9
Type of wiring
Ending
Number of poles
3
Connection type
Other
Exchangeable control gear
No
Constant light output (CLO)
No
Colour temperature adjustable
No
Beam angle adjustable
No
Luminous flux adjustable
No
Max. number of luminaires per miniature circuit breaker B16
13
E
Operation by Bluetooth
No
Photobiological safety according to EN 62471
RG1
Stock and logistics
Height
0.24 m
Width
0.24 m
Depth
0.06 m
Packaging
item
Weight
1.076 kg
HS code
94051190
