Legrand
026677
Switch disconnector
Manufacturer part number: 026677
Serie: DPX-IS
Type: 630
EAN-code: 3245060266776
SKU Omnical: 2304529
Stock: 0.
Estimated lead time: 14 days *
PreOrder
YSA
€
865,35
per item
€
587,57
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
026677 Legrand Switch disconnector
Legrand Switch disconnector DPX-IS630 lastsch.rechts 3P 630A
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Number of poles
3
Rated permanent current Iu
(A)
630
Version as main switch
Yes
Version as maintenance-/service switch
Yes
Version as safety switch
Yes
Version as emergency stop installation
Yes
Width
(mm)
265
Device construction
Complete device in housing
Max. rated operation voltage Ue AC
(V)
690
Rated operation power at AC-23, 400 V
(kW)
252
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
4
Motor drive optional
No
Motor drive integrated
No
Voltage release optional
Yes
Conditioned rated short-circuit current Iq
(kA)
100
Suitable for floor mounting
Yes
Suitable for front mounting 4-hole
Yes
Suitable for front mounting centre
No
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Type of control element
Rocker lever
Interlockable
Yes
Type of electrical connection of main circuit
Screw connection
Degree of protection (IP), front side
IP20
Height
(mm)
200
Depth
(mm)
143.2
Version as reversing switch
No
Rated operating voltage
(V)
230 - 690
Rated permanent current at AC-21, 400 V
(A)
630
Rated short-time withstand current lcw
(kA)
15
Colour control element
Black
Stock and logistics
Height
205 mm
Width
340 mm
Depth
420 mm
Packaging
item
Weight
7.35 kg
HS code
85365080
Country of Origin
IT
