Murrelektronik
54040
Panel feed-through terminal block
Manufacturer part number: 54040
Serie: Interface modules
Type: SV-SUB D 9 .-KL FOR SIGNAL TRANSF
EAN-code: 4048879026499
SKU Omnical: 1192634
Stock: 0.
Estimated lead time: 11 days *
PreOrder
YRO
€
36,02
per item
€
31,66
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
54040 Murrelektronik Panel feed-through terminal block
Murrelektronik Panel feed-through terminal block SV-SUB D 9 .-KL FOR SIGNAL TRANSFER 125 VAC/DC / 2 A
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Connectable conductor cross section fine-strand without cable end sleeve
(mm²)
0.5 - 2.5
Connectable conductor cross section fine-strand with cable end sleeve
(mm²)
0.5 - 4
Connectable conductor cross section solid-core
(mm²)
0.5 - 4
Connectable conductor cross section multi-wired
(mm²)
0.5 - 2.5
Rated current In
(A)
2
Rated voltage
(V)
150
Type of electrical connection 1
Other
Type of electrical connection 2
Screw connection
Connection position
Above
Number of poles
9
Number of clamp positions per pole
1
Mounting method
DIN rail (top hat rail) 35 mm
Material insulation body
Thermoplastic
Operating temperature
(°C)
-20 - 70
Inflammability class of insulation material according to with UL94
Other
Width/grid dimension
(mm)
50
Dimension vertical to mounting plate outer side
(mm)
63
Explosion-tested version 'Ex e'
No
Closing plate required
No
Colour
Green
With integrated feed-through flange
No
Stock and logistics
Height
0.063 m
Width
0.05 m
Depth
0.048 m
Packaging
box
Weight
0.116 kg
HS code
85366990
Country of Origin
CZ
