OBO 2001942
OBO

2001942

Box/housing for surface mounting on the wall/ceiling
Manufacturer part number: 2001942
Serie:
Type: B 9 K M

EAN-code: 4012195536116
SKU Omnical: 1099030

Stock: 74 items.

Delivery time: 1-2 business days.
InStock

H12
€ 827,13 per 100 items
484,70 per 100 items
EUR | Excluding VAT

Quantity
pce
Add to cart
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
paypal
visa
mastercard
wire-transfer
2001942 OBO Box/housing for surface mounting on the wall/ceiling
OBO Box/housing for surface mounting on the wall/ceiling

Datasheet

Max. conductor cross section (mm²)
0
Equipped with
Other
Shape
Square
Mounting method
Wall-/ceiling mounting
For tube diameter
20 mm
Inlet from the rear
No
Length (mm)
94
Width (mm)
94
Depth (mm)
45
Tackable
No
Number of inlets
7
Type of housing feed-through
Thread and prestamping
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP67
Cover
Not transparent
Cover attachment
Screwed
Sealable
Yes
Rated insulation voltage Ui (V)
660
Circuit integrity
None
With screening
No
Weatherproof
No
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None

Stock and logistics

Height
0.095 m
Width
0.115 m
Depth
0.245 m

Packaging
item
Weight
13.5 kg
HS code
39269097
Country of Origin
HU
