5097631
Surge protection device for terminal equipment
Manufacturer part number: 5097631
Serie:
Type: VF110-AC DC
EAN-code: 4012195578154
SKU Omnical: 3041773
Stock: 0.
Estimated lead time: 9 days *
PreOrder
H17
$
293.12
per item
$
167.37
per item
CAD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
5097631 OBO Surge protection device for terminal equipment
OBO Surge protection device for terminal equipment Bliksembarrière voor AC en DC 110V AC
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Mounting method
DIN rail (top hat rail) 35 mm
Nominal voltage AC
(V)
110
Nominal voltage DC
(V)
110
Max. continuous voltage AC
(V)
150
Max. continuous voltage DC
(V)
200
Nominal load current
(A)
20
Nominal discharge surge current (8/20) (L-N)
(kA)
2
Total discharge current (8/20) (L+N-PE)
(kA)
6.5
Voltage protection level
(kV)
0.5
Number of poles
3
With remote signalling contact
No
Signalling at the device
Optic
Max. conductor cross section solid (solid, stranded)
(mm²)
2.5
Max. conductor cross section flexible (fine-strand)
(mm²)
2.5
Category type 3
Yes
With interference suppressor filter
No
Degree of protection (IP)
IP20
Stock and logistics
Height
0.042 m
Width
0.067 m
Depth
0.092 m
Packaging
item
Weight
0.104 kg
HS code
85363030
Country of Origin
HU
