Philips
8719514103887
Pendant luminaire
Manufacturer part number: 8719514103887
Serie: FlexBlend
Type: Pendelarmatuur
EAN-code: 8719514103887
SKU Omnical: 3296481
Stock: 0.
Estimated lead time: 25 days *
PreOrder
P77
€
385,00
per item
€
313,39
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8719514103887 Philips Pendant luminaire
Philips Pendant luminaire SP340P 42S/940 PSD PCS SMT L120 WH
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Lamp holder
None
Suitable for number of lamps
2
Width
(mm)
200
Type of control gear
LED operating device current-controlled
With control gear
Yes
Nominal voltage
(V)
220 - 240
Direct-/indirect proportion separately controllable
No
Material housing
Steel
Colour housing
White
Suitable for light line configuration
Yes
Material cover
Plastic, structured
Suitable for workplace according to EN 12464-1
Yes
Type of grid
None
Reflector
White
Light sharing
Symmetric
Light outlet
Direct
Length
(mm)
1200
With suspension
Yes
Pendant length
(mm)
220 - 2200
Protection class
I
Degree of protection (IP)
IP20
Impact strength
IK02
Luminaire with limited surface temperature, sign "D“
No
With light source
Yes
Suitable for emergency lighting
No
Voltage type
AC
Nominal current
(mA)
125 - 153
Rated luminous flux according to IEC 62722-2-1
(lm)
4200
Colour of light
White
Colour temperature
(K)
4000 - 4000
Colour rendering index CRI
90-100
LED nominal current at constant current
(mA)
205 - 205
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming programmable
Yes
Dimming DSI
No
Dimming RF
No
Dimming potentiometer (integrated)
No
Dimming GPRS
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
No
Light distributor
Diffuser lens/optic/panel
Colour consistency (McAdam ellipse)
SDCM3
Emergency power supply integrated
No
Filament test according to IEC 60695-2-11
850 °C - 30 s
Max. system power
(W)
32
Luminaire efficacy
(lm/W)
131
Power factor
0.9
Height/depth
(mm)
73
Type of wiring
Suitable for through wiring
Number of poles
5
Conductor cross section
(mm²)
0.5
Connection type
Other
Unified Glare Ratio (UGR)
19
Dimming DALI-2
Yes
Flickering value Pst LM
1
Stroboscope effect value SVM
0.4
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Exchangeable control gear
Yes
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
85
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
5
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
E
Max. number of luminaires per miniature circuit breaker B16
15
Max. number of luminaires per miniature circuit breaker C16
15
Operation by Bluetooth
No
Stock and logistics
Height
0.09 m
Width
0.22 m
Depth
1.32 m
Packaging
box
Weight
4.914 kg
HS code
94051190
Country of Origin
PL
