Philips
8719514464452
Downlight/spot/floodlight
Manufacturer part number: 8719514464452
Serie:
Type: Downlight
EAN-code: 8719514464452
SKU Omnical: 4219514
Stock: 0.
Estimated lead time: 18 days *
PreOrder
ZEO
€
35,00
per item
€
19,98
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8719514464452 Philips Downlight/spot/floodlight
Philips Downlight/spot/floodlight DN065B G4 LED20/830_840_865 19W D200 RD
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Suitable for number of lamps
1
Lamp holder
Other
Type of control gear
LED operating device current-controlled
With control gear
Yes
Width
(mm)
225
Nominal voltage
(V)
220 - 240
Material housing
Other
Colour housing
White
Reflector
None
Light sharing
Symmetric
Beam angle
Extreme wide beam >80°
Length
(mm)
225
Height/depth
(mm)
45
Outer diameter
(mm)
225
Protection class
II
Degree of protection (IP)
IP20
Impact strength
IK03
Luminaire with limited surface temperature, sign "D“
Yes
With movement sensor
No
With light source
Yes
Suitable for suspended mounting
No
Suitable for ceiling mounting
Yes
Suitable for traverse mounting
No
Suitable for pedestal/floor mounting
No
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
Adjustability
not adjustable
With light sensor
No
Suitable for lamp power
(W)
17.1 - 20.9
Nominal current
(mA)
82 - 82
Max. system power
(W)
19
Colour temperature
(K)
3000 - 6500
Voltage type
AC
Rated luminous flux according to IEC 62722-2-1
(lm)
2000
Colour of light
Other
Colour rendering index CRI
80-89
Suitable for surface mounting
No
Suitable for built-in mounting
Yes
Suitable for low voltage cable system
No
Surface protection
Powder coating
Material cover
Plastic matt/satinized
Surface brushed
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
None
Light outlet
Direct
Total harmonic distortion
0.3
Rated life time L70/B50 at 25 °C
(h)
30000
Rated ambient temperature according to IEC62722-2-1
(°C)
-20 - 40
Luminous flux
(lm)
2000 - 2000
Power factor
0.9
Built-in height/depth
(mm)
93
Type of wiring
Ending
Number of poles
2
Conductor cross section
(mm²)
0.75
Connectable conductor cross section
(mm²)
0.75 - 2.5
Connection type
Screwed terminal
Emergency power supply integrated
No
Luminaire efficacy
(lm/W)
105
Suitable for workplace according to EN 12464-1
Yes
Covering of the luminaire with thermally insulating material possible
Yes
Filament test according to IEC 60695-2-11
650 °C - 30 s
Photobiological safety according to EN 62471
Other
Colour consistency (McAdam ellipse)
SDCM5
Unified Glare Ratio (UGR)
28
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Dimming DALI-2
No
Flickering value Pst LM
0.7
Stroboscope effect value SVM
0.4
Exchangeable control gear
No
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
No
Beam angle adjustable
No
Max. number of luminaires per miniature circuit breaker B16
55
Max. number of luminaires per miniature circuit breaker C16
95
Suitable for wall mounting
No
Built-in diameter
(mm)
200 - 200
F
Operation by Bluetooth
No
Reflector colour
White
Stock and logistics
Height
0.229 m
Width
0.228 m
Depth
0.053 m
Packaging
box
Weight
0.494 kg
HS code
94051190
