Full catalog
Categorized products only
Philips
8720169500518
Batten luminaire
Manufacturer part number: 8720169500518
Serie:
Type:
EAN-code: 8720169500518
SKU Omnical: 3385043
Stock: 0.
Estimated lead time: 11 days *
PreOrder
ZEN
€
85,00
per item
€
64,94
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8720169500518 Philips Batten luminaire
Philips Batten luminaire BN126C LED25_41_64S/840 PSU L1200
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Lamp holder
Other
Width
(mm)
65
Type of control gear
LED operating device current-controlled
With control gear
Yes
Suitable for emergency lighting
No
Nominal voltage
(V)
220 - 240
Electrical connection with connector system
No
Material
Steel
Colour housing
White
With switch
No
Length
(mm)
1135
Protection class
I
Degree of protection (IP)
IP20
Luminaire with limited surface temperature, sign "D“
No
Covering of the luminaire with thermally insulating material possible
Yes
With light source
Yes
Voltage type
AC
Nominal current
(mA)
90 - 220
Rated luminous flux according to IEC 62722-2-1
(lm)
6400
Colour of light
White
Colour temperature
(K)
4000 - 4000
Colour rendering index CRI
80-89
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Diffuser lens/optic/panel
Emergency power supply integrated
No
Filament test according to IEC 60695-2-11
650 °C - 30 s
With movement sensor
No
Max. system power
(W)
48
Power factor
0.9
Height/depth
(mm)
65
Type of wiring
Suitable for through wiring
Number of poles
3
Conductor cross section
(mm²)
1
Connection type
Push-in clamp
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Exchangeable control gear
No
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
80
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
5
Constant light output (CLO)
No
Colour temperature adjustable
No
Luminous flux adjustable
Positions
Beam angle adjustable
No
E
Operation by Bluetooth
No
Compatible with Casambi
No
No
Luminaire efficacy
(lm/W)
133
Stock and logistics
Height
0.073 m
Width
0.073 m
Depth
1.142 m
Packaging
box
Weight
1.444 kg
HS code
94051190
