Philips
8720169736160
Downlight/spot/floodlight
Manufacturer part number: 8720169736160
Serie:
Type:
EAN-code: 8720169736160
SKU Omnical: 4343346
Stock: 0.
Estimated lead time: 11 days *
PreOrder
ZEO
€
59,50
per item
€
33,97
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
8720169736160 Philips Downlight/spot/floodlight
Philips Downlight/spot/floodlight BVP167 LED24/830_40_65PSU 20W SWB MDU
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Lamp type
LED not exchangeable
Suitable for number of lamps
1
Lamp holder
None
Type of control gear
Not required
With control gear
Yes
Width
(mm)
97
Nominal voltage
(V)
220 - 240
Material housing
Aluminium
Colour housing
Grey
Reflector
None
Light sharing
Symmetric
Beam angle
Extreme wide beam >80°
Length
(mm)
181
Height/depth
(mm)
56
Protection class
I
Degree of protection (IP)
IP65
Impact strength
IK07
Luminaire with limited surface temperature, sign "D“
No
With movement sensor
Yes
With light source
Yes
Suitable for suspended mounting
No
Suitable for ceiling mounting
No
Suitable for traverse mounting
No
Suitable for pedestal/floor mounting
Yes
Suitable for light-track mounting
No
Suitable for clamp-mounting
No
Adjustability
Rotatable
With light sensor
Yes
Suitable for lamp power
(W)
20 - 20
Nominal current
(mA)
0.09 - 0.09
Max. system power
(W)
20
Colour temperature
(K)
3000 - 6500
Voltage type
AC
Rated luminous flux according to IEC 62722-2-1
(lm)
2400
Colour of light
White
Colour rendering index CRI
80-89
Suitable for surface mounting
Yes
Suitable for built-in mounting
No
Suitable for low voltage cable system
No
Surface protection
Powder coating
Material cover
Glass transparent
Surface brushed
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off
No
Dimming phase cut-on
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
No dim function
Yes
Light distributor
Reflector
Light outlet
Direct
Total harmonic distortion
20
Rated life time L70/B50 at 25 °C
(h)
80000
Rated ambient temperature according to IEC62722-2-1
(°C)
25 - 25
Luminous flux
(lm)
2200 - 2400
Power factor
0.8
Type of wiring
Ending
Number of poles
3
Conductor cross section
(mm²)
1
Connectable conductor cross section
(mm²)
1 - 1
Connection type
Other
Emergency power supply integrated
No
Luminaire efficacy
(lm/W)
110
Suitable for workplace according to EN 12464-1
No
Covering of the luminaire with thermally insulating material possible
No
Filament test according to IEC 60695-2-11
650 °C - 30 s
Photobiological safety according to EN 62471
RG0
Colour consistency (McAdam ellipse)
SDCM5
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Dimming DALI-2
No
Flickering value Pst LM
1
Exchangeable control gear
No
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
80
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
(%)
7.5
Constant light output (CLO)
No
Colour temperature adjustable
Positions
Luminous flux adjustable
No
Beam angle adjustable
No
Max. number of luminaires per miniature circuit breaker B16
109
Max. number of luminaires per miniature circuit breaker C16
127
Suitable for wall mounting
Yes
E
Operation by Bluetooth
No
Reflector colour
White
Stock and logistics
Height
0.187 m
Width
0.064 m
Depth
0.103 m
Packaging
box
Weight
0.412 kg
HS code
94054239
