Phoenix Contact
1088129
Fieldbus, decentr. periphery - digital I/O module
Manufacturer part number: 1088129
Serie: Digitale module
Type: AXL SE DO16/1
EAN-code: 4055626888101
SKU Omnical: 3066785
Stock:
4 items.
Delivery time: 1-2 business days.
InStock
SSL Connection
WorldWide Shipping
1088129 Phoenix Contact Fieldbus, decentr. periphery - digital I/O module
Phoenix Contact Fieldbus, decentr. periphery - digital I/O module AXL SE DO16/1
Datasheet
Supply voltage DC
(V)
19.2 - 30
Voltage type of supply voltage
DC
Number of digital inputs
0
Width
(mm)
14.9
Number of digital outputs
16
Digital inputs configurable
No
Digital outputs configurable
No
Type of voltage (input voltage)
DC
Type of digital output
Other
Output current
(A)
0.5
Permitted voltage at output
(V)
24 - 24
Short-circuit protection, outputs available
Yes
Number of HW-interfaces industrial Ethernet
0
Number of interfaces PROFINET
0
Number of HW-interfaces RS-232
0
Number of HW-interfaces RS-422
0
Number of HW-interfaces RS-485
0
Number of HW-interfaces serial TTY
0
Number of HW-interfaces parallel
0
Number of HW-interfaces Wireless
0
Number of HW-interfaces other
0
With optical interface
No
Radio standard Bluetooth
No
Radio standard Wi-Fi 802.11
No
Radio standard GPRS
No
Radio standard GSM
No
Radio standard UMTS
No
IO link master
No
System accessory
Yes
Degree of protection (IP)
IP20
Type of electric connection
Other
Time delay at signal exchange
(ms)
0 - 0
Fieldbus connection over separate bus coupler possible
Yes
Rail mounting possible
No
Wall mounting/direct mounting
No
Front built-in possible
No
Rack-assembly possible
No
Suitable for safety functions
No
Performance level according to EN ISO 13849-1
None
Appendant operation agent (Ex ia)
No
Appendant operation agent (Ex ib)
No
Explosion safety category for gas
None
Explosion safety category for dust
None
Height
(mm)
62.2
Depth
(mm)
62
SIL according to IEC 61508
None
Number of HW-interfaces USB
0
Stock and logistics
Height
0.016 m
Width
0.078 m
Depth
0.124 m
Packaging
box
Weight
0.039 kg
HS code
85389091
Country of Origin
DE
