Siemens
3RA64002CB43
Motor starter/Motor starter combination
Manufacturer part number: 3RA64002CB43
Serie:
Type: IO-LINK C-STARTER;DOL;1-4A
EAN-code: 4011209714854
SKU Omnical: 2047062
Stock: 0.
Estimated lead time: 10 days *
PreOrder
T99
€
601,00
per item
€
399,06
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
3RA64002CB43 Siemens Motor starter/Motor starter combination
Siemens Motor starter/Motor starter combination SIRIUS compact load feeder direct on-line starter for IO-Link, 690 V,
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Rated control supply voltage at AC 50 Hz
(V)
0 - 0
Rated control supply voltage at AC 60 Hz
(V)
0 - 0
Rated control supply voltage at DC
(V)
24 - 24
Voltage type for actuating
DC
Rated operation power at AC-3, 400 V
(kW)
1.5
Width
(mm)
45
Rated operation current Ie
(A)
4
Overload release current setting
(A)
1 - 4
With short-circuit release
Yes
Type of electrical connection of main circuit
Other
Degree of protection (IP)
IP20
Height
(mm)
191
Depth
(mm)
165
Type of motor starter
Direct online starter (DOL)
Rated operation current at AC-3, 400 V
(A)
4
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Ambient temperature, upper operating limit
(°C)
60
Temperature compensated overload protection
No
Release class
Adjustable
Type of electrical connection for auxiliary- and control current circuit
Spring clamp connection
Rail mounting possible
Yes
Supporting protocol for TCP/IP
No
Supporting protocol for PROFIBUS
No
Supporting protocol for CAN
No
Supporting protocol for INTERBUS
No
Supporting protocol for ASI
No
Supporting protocol for MODBUS
No
Supporting protocol for Data-Highway
No
Supporting protocol for DeviceNet
No
Supporting protocol for SUCONET
No
Supporting protocol for LON
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for SERCOS
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for EtherNet/IP
No
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for INTERBUS-Safety
No
Supporting protocol for PROFIsafe
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for other bus systems
Yes
With transformer
No
Number of command positions
2
Suitable for emergency stop
No
Coordination class according to IEC 60947-4-3
Class 2
Number of indicator lights
3
External reset possible
Yes
With fuse
No
Degree of protection (NEMA)
Other
Stock and logistics
Height
0.06 m
Width
0.182 m
Depth
0.229 m
Packaging
item
Weight
1.375 kg
HS code
85364900
Country of Origin
DE
