Siemens
5SP41927
Miniature circuit breaker (MCB)
Manufacturer part number: 5SP41927
Serie:
Type: CIRCUIT BREAKER 10KA 1P C125 1,5MW
EAN-code: 4001869195100
SKU Omnical: 2408816
Stock: 0.
Estimated lead time: 8 days *
PreOrder
S11
$
184.58
per item
$
110.75
per item
USD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
5SP41927 Siemens Miniature circuit breaker (MCB)
Siemens Miniature circuit breaker (MCB) Miniature circuit breaker 230/400 V 10 kA, 1-pole, C, 125 A, D=70 mm
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Rated current
(A)
125
Number of poles (total)
1
Concurrently switching neutral conductor
No
Release characteristic
C
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
(kA)
10
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
(kA)
10
Rated voltage
(V)
400
Additional equipment possible
Yes
Voltage type
AC
Current limiting class
3
Over voltage category
3
Pollution degree
3
Width in number of modular spacings
1.5
Built-in depth
(mm)
70
Degree of protection (IP)
IP20
Number of protected poles
1
Frequency
(Hz)
50 - 50
Suitable for flush-mounted installation
No
Rated insulation voltage Ui
(V)
440
Ambient temperature during operating
(°C)
-25 - 55
Connectable conductor cross section multi-wired
(mm²)
25 - 50
Connectable conductor cross section solid-core
(mm²)
25 - 50
Explosion-proof
No
Flush-mounted installation
No
Stock and logistics
Height
0.033 m
Width
0.081 m
Depth
0.096 m
Packaging
item
Weight
0.263 kg
HS code
85362090
Country of Origin
DE
