Spelsberg
92025001
Box/housing for built-in mounting in the wall/ceiling
Manufacturer part number: 92025001
Serie:
Type: HW 050 H
EAN-code: 4013902170845
SKU Omnical: 4253731
Stock: 0.
Estimated lead time: 7 days *
PreOrder
G36
€
331,00
per 100 items
€
279,03
per 100 items
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
92025001 Spelsberg Box/housing for built-in mounting in the wall/ceiling
Spelsberg Box/housing for built-in mounting in the wall/ceiling HW 050 H inbouwdoos
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Mounting method
Hollow wall
Shape
Round
Construction type
Built-in installation box (device box)
Model
Single
Equipped with
None
Width
(mm)
68
Diameter
(mm)
68
Length
(mm)
68
Inner depth
(mm)
48
For number of electric fittings
1
Mounting switching equipment
Spread
With screws
Yes
Suitable for cable diameter
(mm)
4.6 - 19
Pipe locking
No
Inlet from the rear
Yes
Number of inlets
8
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Green
Degree of protection (IP)
IP30
Cover
None
Cover attachment
Not applicable
Sealable
No
Circuit integrity
None
With screening
No
Air tight
No
Max. conductor cross section
(mm²)
2.5
Luminaire hook mounting
No
Nozzle
None
With nail lugs
No
Provided with revolving ring
No
Connectable
Yes
Depth
(mm)
50 - 50
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
Pipe locking optional
No
Number of included spouts
0
Special application
Other
Suitable for wall/board thickness
(mm)
1 - 40
Cover model
None
0
0
With partition panel
No
Stock and logistics
Height
0.068 m
Width
0.068 m
Depth
0.05 m
Packaging
item
Weight
0.026 kg
HS code
39269097
Country of Origin
DE
