Wago
231-605
Cable connector
Manufacturer part number: 231-605
Serie: Series 231
Type: 231-605
EAN-code: 4044918257169
SKU Omnical: 2682378
Stock:
17 items.
Delivery time: 1-2 business days.
InStock
XNJ
€
3,69
per item
€
3,00
per item
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
231-605 Wago Cable connector
Wago Cable connector 1-draads male steker CAGE CLAMP® 2,5 mm² grijs
Datasheet
Contact type
Pin
Number of plug-in contacts
5
Number of plug-in contact rows
1
Modular spacing contacts
(mm)
5
Modular spacing connections
(mm)
5
Angle contact/conductor connection
180° (horizontal)
Rated current In
(A)
12
Rated voltage
(V)
320
Rated surge voltage
(kV)
4
Over voltage category
III
Pollution degree
2
Connectable conductor cross section fine-strand without cable end sleeve
(mm²)
0.08 - 2.5
Connectable conductor cross section fine-strand with cable end sleeve
(mm²)
0.25 - 1.5
Connectable conductor cross section solid-core
(mm²)
0.08 - 2.5
Connectable conductor cross section multi-wired
(mm²)
0.08 - 2.5
Type of electric connection
Spring clamp connection
Connectable cable type
Tubular cable
Material of contact surface
Tin
Material contact
Other copper alloys
Material insulation body
Thermoplastic
Material housing
Plastic
Housing coating
Not applicable
Colour housing
Grey
Inflammability class of insulation material according to with UL94
V0
With protective conductor
No
Operating temperature
(°C)
-60 - 100
Degree of protection (IP), mounted
IP10
Type of connection
Printed circuit board to cable
Number of poles
5
Coating housing
Uncoated
Stock and logistics
Height
0.04 m
Width
0.172 m
Depth
0.254 m
Packaging
box
Weight
0.465 kg
HS code
85366930
Country of Origin
DE
