Wago
232-143/047-000
Printed circuit board connector
Manufacturer part number: 232-143/047-000
Serie: Series 232
Type: 232-143/047-000
EAN-code: 4044918623599
SKU Omnical: 3014232
Stock: 0.
Estimated lead time: 9 days *
PreOrder
XNJ
€
670,00
per 100 items
€
545,38
per 100 items
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
232-143/047-000 Wago Printed circuit board connector
Wago Printed circuit board connector THT female steker recht Rastermaat 5 mm grijs
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Connector model
Free connector
Contact type
Pin
Number of plug-in contacts
13
Number of plug-in contact rows
1
Modular spacing contacts
(mm)
5
Modular spacing connections
(mm)
5
Angle PCB/contact
90° (upwards vertical)
Rated current In
(A)
12
Rated voltage
(V)
320
Rated surge voltage
(kV)
4
Over voltage category
III
Pollution degree
2
Material of contact surface
Tin
Type of electric connection
Soldering connection
Length pin
(mm)
5
Suitable for PCB thickness
(mm)
1.5
Material insulation body
Thermoplastic
Colour housing
Grey
Inflammability class of insulation material according to with UL94
V0
Operating temperature
(°C)
-60 - 85
Type of PCB fastening
Connecting contact
Type of fastening
Solder
Packaging type
Carton (box)
Type of banding
None
Type of connection
Flexible PCB-connector
Number of poles
13
Stock and logistics
Height
0.04 m
Width
0.256 m
Depth
0.318 m
Packaging
box
Weight
0.518 kg
HS code
85366990
Country of Origin
DE
