Wago
236-404/334-604
Printed circuit board terminal
Manufacturer part number: 236-404/334-604
Serie: Series 236
Type: 236-404/334-604
EAN-code: 4044918769488
SKU Omnical: 3015345
Stock: 0.
Estimated lead time: 9 days *
PreOrder
XNK
€
132,00
per 100 items
€
107,45
per 100 items
EUR | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
236-404/334-604 Wago Printed circuit board terminal
Wago Printed circuit board terminal THR-printklem 2,5 mm² Rastermaat 5 mm zwart
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Height
(mm)
13
Number of electrical connections
4
Number of levels
1
Modular spacing connections
(mm)
5
Angle PCB/conductor connection
45°/135° (downwards inclined)
Rated current In
(A)
24
Rated voltage
(V)
320
Rated surge voltage
(kV)
4
Over voltage category
III
Pollution degree
2
Connection type conductor
Spring clamp connection
Connectable conductor cross section solid-core
(mm²)
0.08 - 2.5
Connectable conductor cross section fine-strand with cable end sleeve
(mm²)
0.25 - 1.5
Connectable conductor cross section fine-strand without cable end sleeve
(mm²)
0.08 - 2.5
Connectable conductor cross section multi-wired
(mm²)
0.08 - 2.5
Connection type PCB
THR connection
Material connection surface
Tin
Length pin
(mm)
3.6
Material insulation body
Thermoplastic
Colour housing
Black
Inflammability class of insulation material according to with UL94
V2
Operating temperature
(°C)
-60 - 115
Type of PCB fastening
Connecting contact
Type of fastening
Solder
Packaging type
Other
Type of banding
None
Stock and logistics
Height
0.076 m
Width
0.106 m
Depth
0.276 m
Packaging
box
Weight
0.941 kg
HS code
85369010
Country of Origin
CH
