Wago
740-109
Printed circuit board terminal
Manufacturer part number: 740-109
Serie: Series 740
Type: 740-109
EAN-code: 4055143237826
SKU Omnical: 1601303
Stock: 0.
Estimated lead time: 39 days *
PreOrder
XNK
$
4.35
per item
$
3.54
per item
USD | Excluding VAT
Quantity
items
Contact us for a quote with volume pricing.
SSL Connection
WorldWide Shipping
740-109 Wago Printed circuit board terminal
Wago Printed circuit board terminal Printklem 2,5 mm² Rastermaat 5 mm grijs
* Lead time based on standard manufacturer lead time and historical data. Omnical confirms lead times upon ordering and upon request.
Datasheet
Height
(mm)
18.2
Number of electrical connections
9
Number of levels
1
Modular spacing connections
(mm)
5
Angle PCB/conductor connection
0°/180° (horizontal)
Rated current In
(A)
16
Rated voltage
(V)
320
Rated surge voltage
(kV)
4
Over voltage category
III
Pollution degree
2
Connection type conductor
Spring clamp connection
Connectable conductor cross section solid-core
(mm²)
0.08 - 2.5
Connectable conductor cross section fine-strand with cable end sleeve
(mm²)
0.25 - 1.5
Connectable conductor cross section fine-strand without cable end sleeve
(mm²)
0.08 - 2.5
Connectable conductor cross section multi-wired
(mm²)
0.08 - 2.5
Connection type PCB
Soldering connection
Material connection surface
Tin
Length pin
(mm)
5.1
Material insulation body
Thermoplastic
Colour housing
Grey
Inflammability class of insulation material according to with UL94
V0
Operating temperature
(°C)
-60 - 105
Type of PCB fastening
Connecting contact
Type of fastening
Solder
Packaging type
Other
Type of banding
None
Stock and logistics
Height
0.1 m
Width
0.105 m
Depth
0.275 m
Packaging
box
Weight
1.389 kg
HS code
85369010
Country of Origin
PL
